Yonos enables single luminaires, continuous lines and light structures to be realised – with a consistent, coherent design and quality of light. A wide range of luminaire, functional and decorative modules solve the most diverse lighting tasks in the office – flexibly even after initial planning. Fast, secure and cost-effective mounting thanks to the patented lock and proven contacting technology.

Experience the Yonos series

Configure your product

Name	Rated luminous flux	Connected load	Colour temperature	Luminous efficacy	Light distribution
YNS DH 7x65 PW22 24-840 DD 03 9002412919 New	2400 lm	14,4 W	4000 K	167 lm/W	direct/wide/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW22 16-840 DD 03 9002412927 New	1600 lm	9,8 W	4000 K	163 lm/W	direct/wide/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW22 16-840 DD 01 9002412946 New	1600 lm	9,8 W	4000 K	163 lm/W	direct/wide/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW22 16-830 DD 01 9002414113 New	1600 lm	10,6 W	3000 K	151 lm/W	direct/wide/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-9TW DD 05 9002416003 New	1000 lm	7,3 - 7,8 W	2700 - 6500 K	128 - 137 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-9TW DD 03 9002417211 New	1000 lm	7,3 - 7,8 W	2700 - 6500 K	128 - 137 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-9TW DD 01 9002417210 New	1000 lm	7,3 - 7,8 W	2700 - 6500 K	128 - 137 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-940 DD 05 9002417222 New	1000 lm	7,6 W	4000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-940 DD 03 9002417220 New	1000 lm	7,6 W	4000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-940 DD 01 9002417216 New	1000 lm	7,6 W	4000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-930 DD 05 9002414129 New	1000 lm	7,6 W	3000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-930 DD 03 9002417219 New	1000 lm	7,6 W	3000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-930 DD 01 9002417215 New	1000 lm	7,6 W	3000 K	132 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-840 DD 05 9002417221 New	1000 lm	6,5 W	4000 K	154 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-840 DD 03 9002414098 New	1000 lm	6,5 W	4000 K	154 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-840 DD 01 9002412921 New	1000 lm	6,5 W	4000 K	154 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-830 DD 05 9002416490 New	1000 lm	6,9 W	3000 K	145 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-830 DD 03 9002415089 New	1000 lm	6,9 W	3000 K	145 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 PW19 10-830 DD 01 9002412915 New	1000 lm	6,9 W	3000 K	145 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-940 DD 05 9002417158 New	2400 lm	16,3 W	4000 K	147 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-940 DD 03 9002417149 New	2400 lm	16,3 W	4000 K	147 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-940 DD 01 9002417102 New	2400 lm	16,3 W	4000 K	147 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-930 DD 05 9002417157 New	2400 lm	17 W	3000 K	141 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-930 DD 03 9002417148 New	2400 lm	17 W	3000 K	141 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
YNS DH 7x65 DW19 24-930 DD 01 9002417101 New	2400 lm	17 W	3000 K	141 lm/W	direct/wide (UGR19)/symmetric	Add to watchlist Add to product comparison Downloads
