Switch now. Save energy.
ARE YOU READY FOR A TECHNOLOGY SHIFT?
Quality of light, energy efficiency and sustainability: those who refurbish their lighting now invest in more well-being, greater safety and higher quality of life. In every application, TRILUX accompanies you through the entire process, from office to logistics, indoor and outdoor. Find out how you can benefit from a new lighting system, and why retrofitting is not necessarily a sustainable solution for your LED refurbishment. Find out why you shouldn’t wait any longer with your LED refurbishment – SWITCH NOW. SAVE ENERGY.
With an LED refurbishment you can achieve up to 85% in energy savings and improve the quality of light. Intelligent light management provides flexibility for the future. Efficient lighting solutions amortise in a short time.
Refurbish now and save!
Nothing to give away? Cut energy costs by up to 85 percent!
£
Net savings per year
Energy price
Calculation example: Production hall at TRILUX in Arnsberg with approx. 2,000 m² with a previous inventory of 328 E-Line lights T8, 1 x 58W, VVG (21,648 W), which were replaced by E-Line Next Active lights, 6,000 lm, 39 W ( 12,792 W) were replaced. The new lighting system makes it possible, in the spirit of Human Centric Lighting (HCL), to adapt the color temperature to the course of the day of natural light (circadian course) and to set an increased lighting level if necessary.
The calculation shown here is based on 4,000 operating hours per year, with regulated operation of 500 lx. The maximum available illuminance of 880 lx can be accessed if required.
£ per kWh
Compare
£
Net savings per year
Energy price
Calculation example: Office with approx. 120 m2 with 18 T8 louvre lights, 4x18W, VVG (1,512 W) replaced by 18 Creavo M84 lights, 4,200 lm, 25 W (450W). 2,750 operating hours annually. Additional savings through daylight-dependent control: 55%.
£ per kWh
Compare
£
Net savings per year
Energy price
Calculation example: 120 continuous-row equipment racks, T8, 1 x 58W, VVG (7,920W,) replaced by 120 equipment racks 78IP50HE LDAN 40 (2,640 W), 216 spotlights HIT 35 W (9,288 W), replaced by 216 LED spotlights Canilo 3,000 lm (4,104W). 3,600 operating hours annually.
£ per kWh
Compare
£
Net savings per year
Energy price
Calculation example: Classroom with 10 T8 louvre lights, 1 x 58W, VVG (660 W), replaced by 8 OPENDOACT D2 lights, 4200 lm and 2 OPENDO D2 panel lights, 5900 lm (264 W + 70 W). 1,400 operating hours annually. Additional savings through presence detection and daylight-dependent control: 65%.Additional savings through presence detection and daylight-dependent control: 65%.
£ per kWh
Compare
£
Net savings per year
Energy price
Calculation example: Parking lot with 20 mast lights, HIT 150W (3,260 W) replaced by 20 JOVIE70 mast lights, 7,500 lm (1,340 W). 2,000 operating hours annually.
£ per kWh
Compare
£
Net savings per year
Energy price
Calculation example: Corridor areas of a nursing home with 130 3331W diffuser lights, 1 x T5 35W (5,070 W), each converted with an LEDKIT 3331 D3 (2,600 W). 8,760 operating hours annually. Additional savings through presence detection reduced night light: 40%.
£ per kWh
Compare
References
Why does a refurbishment with LED worthwhile?
Energy costs, lamp ban & sustainability
New rules due to lamp bans
Regulations on energy efficiency (Ecodesign Directive) and the use of mercury in light sources (RoHS Directive) make refurbishment with LED lights unavoidable in the long term. The following light sources may no longer be placed on the market from 2023:
No longer on sale from September 1, 2023
T8 linear fluorescent (2’, 4’ & 5’)
No longer on sale from February 1, 2024
Compact fluorescent (CFLni)
T5 linear fluorescent
T8 linear fluorescent (other lengths)
Retro Fit vs. 1:1 Exchange
Fluorescent lamp out, retrofit-solution in, done?
In theory, retrofit conversion is quick and easy. In practice, however, the effort involved is often underestimated.
Cutting costs with LED refurbishment
The LED refurbishment of lighting systems can be an effective way to save energy and upgrade to state-of-the-art technology. Modern LED lighting technologies allow you to significantly reduce energy consumption and improve the quality of light at the same time.
TRILUX offers the following LED refurbishment options which also simplify your building-specific planning:
1. New lighting concept based on all building-specific requirements
2. Direct replacement of old luminaires for economical LED luminaires
3. Design of customised solutions in line with heritage building or health protection requirements
New system
New design based on building-specific requirements with professional lighting design and light management.
1:1 replacement
Replacement of existing old luminaires for professional LED luminaires at a ratio of 1:1.
What do I use for the refurbishment project?
Just a few steps to the right LED luminaire for a 1:1 refurbishment
With our intelligent online refurbishment wizard you can find the right replacement product for your outdated conventional lighting in just a few steps. Even if you don't have all the data at hand, the tool guides you through the selection process. Why not give it a try right now?
The ideal refurbishment solution identified in next to no time.
